Boiler Feed Water Treatment System
♦ Main Application:
Industrial boiler water treatment system engineered to reduce scaling, corrosion, and energy loss, ensuring efficient operation, lower maintenance costs, and long-term reliability.
Boiler Feed Water Treatment System
A Boiler Feed Water Treatment System is designed to produce high-quality feed water for industrial boilers, steam boilers, thermal power systems, heating plants, food processing facilities, textile factories, chemical plants, pharmaceutical factories, and manufacturing industries.
CHONGYANG WATER boiler feed water treatment systems combine filtration, water softening, reverse osmosis, deaeration, and chemical dosing technologies to improve boiler efficiency, reduce scaling, and minimize corrosion risks.
What Is a Boiler Feed Water Treatment System?
A Boiler Feed Water Treatment System is an integrated water treatment solution designed to remove impurities that affect boiler performance, steam quality, heat transfer efficiency, and equipment lifespan.
- Multi-Media Filter
- Activated Carbon Filter
- Water Softener
- Reverse Osmosis System
- Degassing / Deaeration System
- Chemical Dosing System
- Feed Water Tank
- Boiler Feed Pump
- Online Monitoring Instruments
- PLC Control System
Technical Specifications
Typical Boiler Feed Water Quality
| Parameter | Typical Value |
|---|---|
| Hardness | < 0.03 mmol/L |
| Conductivity | Customized According to Boiler Pressure |
| TDS | Low Level |
| Silica | Controlled |
| Iron | < 0.1 mg/L |
| Dissolved Oxygen | < 0.02 mg/L with deaeration |
| pH | 8.5 – 9.5 |
System Specifications
| Parameter | Specification |
|---|---|
| Capacity Range | 1 – 200 m³/h |
| Feed Water Source | Municipal Water / Well Water |
| Pretreatment | MMF + ACF |
| Softening System | Duplex / Simplex |
| RO Configuration | Single Pass / Double Pass |
| Recovery Rate | 65 – 80% |
| Deaeration System | Optional |
| Chemical Dosing | Optional |
| Control System | PLC + HMI |
| Automation Level | Fully Automatic |
Features & Advantages
Production Process
This process removes hardness, dissolved salts, oxygen, and contaminants that can negatively affect boiler performance.
Looking for a Reliable Boiler Feed Water Treatment System?
CHONGYANG WATER provides complete boiler feed water treatment solutions for industrial boilers, steam generators, power plants, food processing facilities, textile factories, chemical plants, and manufacturing industries.
Contact our engineering team to receive feed water analysis, customized process design, utility consumption calculation, P&ID drawings, layout drawings, technical proposals, and competitive quotations.
