SPF Animal Drinking Water System
♦ Main Application:
High-purity water treatment system for SPF laboratory animals, designed to deliver safe, stable, and microbiologically controlled drinking water for research and biomedical use.
SPF Animal Drinking Water Treatment System
An SPF Animal Drinking Water Treatment System is a specialized water purification solution designed to provide high-quality drinking water for Specific Pathogen Free laboratory animals.
CHONGYANG WATER SPF Animal Drinking Water Treatment Systems integrate RO, UF, UV sterilization, endotoxin control, sanitary storage, and continuous distribution loop technologies to ensure stable microbiologically controlled drinking water.
What Is an SPF Animal Drinking Water Treatment System?
It is a dedicated water purification system designed to produce microbiologically controlled drinking water for laboratory animal facilities, biomedical research centers, pharmaceutical research, vaccine studies, toxicology testing, and life science research.
- Bacteria and endotoxin control
- Virus and organic contaminant reduction
- Chlorine residual and heavy metal removal
- Stable water quality for experimental reproducibility
- Suitable for mice, rats, rabbits, guinea pigs, and non-human primates
Technical Specifications
Water Quality Specifications
| Parameter | Typical Value |
|---|---|
| Conductivity | ≤ 5 μS/cm |
| TOC | ≤ 100 ppb |
| Endotoxin | ≤ 0.25 EU/ml |
| Bacteria | < 10 CFU/ml |
| Turbidity | < 0.1 NTU |
| Chlorine | Not Detectable |
| Hardness | Not Detectable |
| Water Quality | SPF Animal Drinking Water |
System Specifications
| Parameter | Specification |
|---|---|
| Capacity Range | 0.5 – 50 m³/h |
| Feed Water Source | Municipal Water / Well Water |
| Pretreatment | MMF + ACF + Softener |
| RO Configuration | Single Pass / Double Pass |
| UF Membrane | Endotoxin Removal UF |
| UV Sterilization | 254 nm |
| Storage Tank Material | SS316L |
| Distribution Material | SS316L |
| Control System | PLC + Touch Screen |
| Automation Level | Fully Automatic |
| Sanitization Method | UV / Ozone / Hot Water |
Distribution System Specifications
| Parameter | Specification |
|---|---|
| Distribution Type | Continuous Circulation |
| Loop Material | SS316L |
| Vent Filter | 0.2 μm |
| Sanitization Frequency | Programmable |
| Monitoring | Conductivity / Temperature |
| Expansion Capability | Modular |
Features & Advantages
Application Industries
Production Process
This multi-stage treatment process ensures continuous production of microbiologically controlled drinking water for SPF animal facilities.
Looking for a Reliable SPF Animal Drinking Water Treatment System?
CHONGYANG WATER provides complete SPF animal drinking water solutions for biomedical research centers, pharmaceutical laboratories, university research facilities, animal breeding centers, and biotechnology institutes.
Contact our engineering team to receive raw water analysis, customized process design, water quality evaluation, P&ID drawings, layout drawings, technical proposals, and competitive quotations.
